Blauberg 150mm (6") Calm Bathroom Extractor Fan with PIR - CALMCHROME150IR

Quick Find Code: CALMC150IR

5 Year Warranty
Free Next Day Delivery!*
  • High airflow – Up to ~318 m³/h for larger bathrooms and long duct runs.
  • Automatic PIR activation – Motion-sensor control for hands-free ventilation.
  • Quiet operation – Low-noise performance (~33 dB(A)) with anti-vibration mounts.
  • Bathroom-safe – IP45 rated for Zones 1 & 2 when installed correctly.
  • Premium finish & reliability – Chrome design with a 5-year motor warranty.

Blauberg 150mm (6") Calm Bathroom Extractor Fan with PIR - CALMCHROME150IR

Quick Find Code: CALMC150IR

5 Year Warranty
Free Next Day Delivery!*
  • High airflow – Up to ~318 m³/h for larger bathrooms and long duct runs.
  • Automatic PIR activation – Motion-sensor control for hands-free ventilation.
  • Quiet operation – Low-noise performance (~33 dB(A)) with anti-vibration mounts.
  • Bathroom-safe – IP45 rated for Zones 1 & 2 when installed correctly.
  • Premium finish & reliability – Chrome design with a 5-year motor warranty.

£183.45 (inc. VAT)

Show ex. VAT

Blauberg

Product Overview

This model is part of the “Calm” series from Blauberg and is built for larger bathrooms or wet-rooms, with a 150 mm (6″) duct connection and a high airflow specification of up to ~ 318 m³/h (≈ 88 l/s).  It uses a mixed‐flow impeller design that supports longer duct runs and includes an anti-back-draft shutter to prevent unwanted outside airflow when the fan is off.

What sets this “IR” variant apart from standard models is the built-in PIR (motion) sensor which automatically triggers extraction when occupancy or movement is detected. That makes it especially suited for bathrooms, shower rooms or utility spaces where automatic ventilation is beneficial. The model still preserves the quiet-running design: German-engineered motor, anti-vibration mounts, and a low sound level (~33 dB(A) measured in other Calm 150 versions).

From an installation and usage viewpoint, this fan carries an IP45 rating and is approved for mounting in bathroom Zones 1 and 2 when wired correctly — meaning it can be safely placed near showers or baths (subject to local regulations). The chrome finish offers a modern aesthetic and the durable build is backed by a 5-year warranty on the motor. For wiring the PIR version, you’ll typically have live and neutral inputs, plus often a switched live or sensor signal—so professional installation is recommended.

Downloads

Download calm-100-data-sheet

Specification

2021 Energy RatingA+
Bathroom Zones1, 2
Battery BackupYes
CurrentAC
Current Amps0.1 A
Domestic or CommercialDomestic
Duct Size Diameter150 mm
Energy RatingA+
Frequency60 Hz
IP RatingIP45
Main Switch Rated Current240 A
Maximum Airflow318 m³/h
Max Operating Humidity0.9 %
MountingWall, Ceiling
Noise Level Maximum33 dB
power consumption19 W
Wattage19 W
Height190 mm
Length111 mm
Weight1 kg
