Product Overview

The Vent-Axia Lo Carbon Centra T Extractor Fan has an adjustable overrun timer. It is a dual speed continuous running fan for kitchens, utility rooms, bathrooms and toilet, with trickle speed selection at installation. Switch live to boost with linked in overrun timer (adjustable up to 30 minutes).

Criteria

• Specification:
  • Extract Performance (l/s) Low: 6
  • Extract Performance (l/s) High: 9
  • Extract Performance (l/s) Boost: 15
  • Power consumption Low: 1.4W
  • Power consumption High: 1.6W
  • Power consumption Boost: 2.4W
  • Sound dB(A)@ 3m Low: 10.8
  • Sound dB(A)@ 3m High: 15.5
  • Sound dB(A)@ 3m Boost: 25.2
  • Dimensions: H: 160mm x W: 160mm x D: 150mm
  • Product Weight: 1.75kg
• Features:
  • Part F compliant, System 3 Continuous mechanical extract
  • SAP Appendix Q eligible - Low SFP on SAP Q
  • Quietest dMEV available
  • Discreet, tasteful styling
  • Single fan for use in all applications
  • IPX4 rated - IPX7 rated (SELV)
  • Constant volume option
  • Normal and Boost speeds
  • Lo-Carbon motor offering 90% energy savings and long life
  • Suitable for wall, ceiling, panel and window mounting
• Guarantee: 5 Years
• Manufacturer Code: 442954

Features

• Part F compliant, System 3 Continuous mechanical extract
• SAP Appendix Q eligible - Low SFP on SAP Q
• Quietest dMEV available
• Discreet, tasteful styling
• Single fan for use in all applications
• IPX4 rated - IPX7 rated (SELV)
• Constant volume option
• Normal and Boost speeds
• Lo-Carbon motor offering 90% energy savings and long life
• Suitable for wall, ceiling, panel and window mounting

Specification

• Extract Performance (l/s) Low: 6
• Extract Performance (l/s) High: 9
• Extract Performance (l/s) Boost: 15
• Power consumption Low: 1.4W
• Power consumption High: 1.6W
• Power consumption Boost: 2.4W
• Sound dB(A)@ 3m Low: 10.8
• Sound dB(A)@ 3m High: 15.5
• Sound dB(A)@ 3m Boost: 25.2
• Dimensions: H: 160mm x W: 160mm x D: 150mm
• Product Weight: 1.75kg

Specification

Duct Size Diameter	105 mm
Extractor Type	Axial
Fan Size Diameter	100 mm
Fan Size Diameter Inches	4 INCH
Fan Speeds	3
Finish Or Colour	White
IP Rating	IPX4
Mounting	Ceiling, Panel, Wall, Window
Room Application	Bathroom, Toilet
Timer	Yes
Voltage	240 v
Depth	168 mm
Height	164 mm
Width	168 mm
