Xpelair RX9 Commercial Roof Fan - 90424AW

Quick Find Code: 90424AW

4 Year Warranty
Free Delivery on orders over £30 (excluding Highlands and Islands)

Specifications

Applicable AreaBathroom, Laundry Room, Office, Toilet
Backdraft ShutterYes
Collection NameRX9
Duct Size Diameter257 mm
Extractor TypeAxial
Fan Size Diameter225 mm

Xpelair RX9 Commercial Roof Fan - 90424AW

Quick Find Code: 90424AW

4 Year Warranty
Free Delivery on orders over £30 (excluding Highlands and Islands)

Specifications

Applicable AreaBathroom, Laundry Room, Office, Toilet
Backdraft ShutterYes
Collection NameRX9
Duct Size Diameter257 mm
Extractor TypeAxial
Fan Size Diameter225 mm

£219.56 (inc. VAT)

Show ex. VAT

Buy more, save more!

QuantityPrice (inc. VAT)Saving Per Item
3+£215.17Save 2%
6+£212.98Save 3%

Product Overview

We are delighted to offer this unit with a free three year guarantee - giving you an additional year's peace of mind on top of Xpelair's standard two year guarantee.

This Xpelair RX9 model is a neat way of ventilating through glazed and solid roofs and can be used vertically in windows on exposed sites such as coastal areas and high rise buildings. The commercial duty roof fans are particularly suitable for pubs, restaurants, offices, kitchens, factories, and squash courts, schools in areas like changing rooms, and kiln rooms and a wide range of shops. This contoured high gloss white housing is sleekly styled. For safety, a finger guard is integrated into the ultra slim high gloss ABS fascia. The UV stabilised roof cowl assembly is a generous size to provide weather protection at all angles. They are suitable for single and sealed double glazed windows and panels up to 25mm. Installation in wire cast and sealed double glazed roof lights is rapid using Xpelair's unique metal ladderstrip and screw system ensuring a secure and weather-tight optional roof mounting plate allows this model to be fitted to dressed curbs.

Criteria

  • Specification:
    • 2 Speed
    • 430-511 (FID, m3/h) Extract Performance
    • 119-142 (FID, l/s) Extract Performance
    • 384-438 (FID, m3/h) Intake Performance
    • 107-122 (FID, l/s) Intake Performance
    • 49-52 (dB(A)@3m) Sound Pressure Level
    • 41 W (Electrical Power Rating)
    • 257 mm (Hole Diameter)
    • 25 mm (Max Wall Thickness)
    • 4.5 Kg (Weight)
    • 3 Year Guarantee
  • Features:
    • High performance extract only axial flow ventilation unit.
    • Operated by remote On/Off switch (not supplied)
    • Suitable for single and sealed double glazed windows and panels up to 25mm.
    • Built in electrothermal shutter cassette.
    • Passive trickle vent option for background ventilation with fan Off.
    • Easy clean high gloss ABS housing.
    • Roof cowl assembly in UV stabilised material provides weather protecion at all roof angles.
    • Unique metal ladderstrip / screw connection to external grille for security and weathertight seal.
    • High Performance intake/extract axial flow ventilation unit.
    • Choice of optional controllers.
    • Tamper-proof internal connection safety plug and socket.
    • Supply voltage 220-240V 50Hz.
    • Extract Only
  • Guarantee: 4 Years
  • Manufacturer Code: 90424AW

Features

  • High performance extract only axial flow ventilation unit.
  • Operated by remote On/Off switch (not supplied)
  • Suitable for single and sealed double glazed windows and panels up to 25mm.
  • Built in electrothermal shutter cassette.
  • Passive trickle vent option for background ventilation with fan Off.
  • Easy clean high gloss ABS housing.
  • Roof cowl assembly in UV stabilised material provides weather protecion at all roof angles.
  • Unique metal ladderstrip / screw connection to external grille for security and weathertight seal.
  • High Performance intake/extract axial flow ventilation unit.
  • Choice of optional controllers.
  • Tamper-proof internal connection safety plug and socket.
  • Supply voltage 220-240V 50Hz.
  • Extract Only

Short Description

Xpelair RX9 Commercial Roof Fan (90424AW)

Specification

  • 2 Speed
  • 430-511 (FID, m3/h) Extract Performance
  • 119-142 (FID, l/s) Extract Performance
  • 384-438 (FID, m3/h) Intake Performance
  • 107-122 (FID, l/s) Intake Performance
  • 49-52 (dB(A)@3m) Sound Pressure Level
  • 41 W (Electrical Power Rating)
  • 257 mm (Hole Diameter)
  • 25 mm (Max Wall Thickness)
  • 4.5 Kg (Weight)
  • 3 Year Guarantee

Specification

Applicable AreaBathroom, Laundry Room, Office, Toilet
Backdraft ShutterYes
Collection NameRX9
Duct Size Diameter257 mm
Extractor TypeAxial
Fan Size Diameter225 mm
Finish Or ColourWhite
Lip Depth117 mm
Minimum Voltage220 v
MountingRoof
Number Of Speeds2
Voltage240 v
Height438 mm
Weight4.5 KG
Width438 mm
