Dimplex Over Door Heater 4.5kW Air Curtain White - AC45W

Product Overview

Dimplex Over Door Heater 4.5kW Air Curtain White - AC45W

The Dimplex AC45W 4.5kW Over Door Heater is designed for installation above single commercial doorways where higher heat output is required. Ideal for retail spaces, offices, and customer-facing environments, it produces a strong curtain of warm air that helps maintain indoor comfort while doors remain open, reducing heat loss and improving energy efficiency.

Delivering an air velocity of 5.5m/s, the AC45W helps limit cold air ingress and stabilise internal temperatures at busy entrances. Operating at 52.0dB(A), it remains suitable for use in public and retail environments without causing unnecessary disruption.

Once commissioned via the Dimplex ConfigR App, the heater offers advanced temperature control between 7–32°C, seven-day scheduling, and energy-saving boost and advance functions. For everyday operation, onboard rocker switches allow easy selection between fan-only, half-heat, and full-heat modes. With a powder-coated steel fascia, EnduroTech motor technology, and integrated thermal safety cut-outs, the AC45W is built for dependable commercial use.

Downloads

Download dimplex-aircurtains-spec-sheet

Download dimplex-aircurtains-installation-guide

Specification

Applicable Area	Commercial, Commercial Premises, Hospitality, Office, Retail Outlet
Colour	White
Domestic or Commercial	Commercial, Office
Fan Function	Yes
Housing Material	Steel
Installation Kit	Yes
IP Rating	IP21
Material	Steel
Maximum Set Temperature	32 °C
Minimum Set Temperature	7 °C
Mounting	Wall
Noise Level Maximum	52 dB
Number of Power Settings	2
Number Of Speeds	2
Plug Supplied	Installed Product ( No Plug )
power consumption	4500 W
Remote Control	Yes (Via App)
Thermostat	Yes (Integrated)
Timer	Yes
Timer Mode	7 Day
Type Of Heater	Air Curtain
Warranty Notes	2 Year Guarantee
Depth	139 mm
Height	214 mm
Weight	57 kg
Width	921 mm
