Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Internal Shutters, Manual - WF230MP

Quick Find Code: WF230MP

3 Year Warranty
Free Next Day Delivery!*
  • Single-Speed
  • Noise Level 50dBA at 3m
  • Extraction Rate 668m³/hr
  • Wall or Window-Mounted
  • Auto-Shutter

Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Internal Shutters, Manual - WF230MP

Quick Find Code: WF230MP

3 Year Warranty
Free Next Day Delivery!*
  • Single-Speed
  • Noise Level 50dBA at 3m
  • Extraction Rate 668m³/hr
  • Wall or Window-Mounted
  • Auto-Shutter

£194.93
£136.45 (inc. VAT)

You save: £58.48

Show ex. VAT

IN STOCK

Manrose
  • American Express
  • Apple Pay
  • Google Pay
  • Maestro
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
  • Iwoca pay

Please add quantity to a product to add it to cart

Product

Fan
Speeds

IP
Rating

Extraction
Rate Ltr/Sec

Timer

Humidistat

Status

Price

Qty

Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Internal Shutters, Manual - WF230MP

Fan
Speeds

IP
Rating IP24

Extraction
Rate Ltr/Sec

Timer No

Humidistat No

In Stock

£136.45

(inc. VAT)

Attribute Value

Manrose 230mm (9") Window Extractor Fan With Internal Shutters, Automatic - WF230A

Fan
Speeds

IP
Rating IP44

Extraction
Rate Ltr/Sec

Timer No

Humidistat No

In Stock

£115.45

(inc. VAT)

Attribute Value

Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Fixed Grill - WF230P

Fan
Speeds

IP
Rating IP44

Extraction
Rate Ltr/Sec

Timer No

Humidistat No

In Stock

£102.43

(inc. VAT)

Attribute Value

Manrose 230mm (9") Wall/Window Extractor Fan with Fixed Grill - WF230S

Fan
Speeds

IP
Rating IP44

Extraction
Rate Ltr/Sec

Timer No

Humidistat No

Sold Out

£110.20

(inc. VAT)

Attribute Value

Add To Cart

Product Overview

The WF230MP is designed for wall or window mounting in commercial or larger-domestic settings, offering a substantial extract rate of approximately 668 m³/h (≈ 185 litres/second). Its 230 mm diameter and axial fan design make it suitable for demanding environments such as offices, shops, restaurants, utility zones and more.

What sets the WF230MP apart is the manual pull-cord operated internal back-draught shutters, which also serve to start the fan when pulled. These internal shutters are built into the housing behind the grille, helping prevent unwanted ingress of draughts when the fan is off and maintaining a clean visual finish.

On the technical and installation side, the fan operates on a typical 220-240 V AC supply, uses a robust motor with pre-oiled bearings for long life, consumes around 41 W, and is rated for standard ambient conditions up to 40 °C. The unit is designed for installation through a standard ~260 mm hole and must be mounted out of reach of bath/shower users and at least 1.8 m above the floor.

Specification

Applicable AreaCommercial, Kitchen, Laundry Room, Office, Warehouse
Domestic or CommercialCommercial
Duct Size Diameter230 mm
Extractor TypeAxial
Fan Size Diameter9 in
Finish Or ColourWhite
HumidistatNo
IP RatingIP24
Minimum Voltage220 V
MountingWall, Window
MPNWF230MP
Noise Level Maximum50 dB
power consumption41 W
TimerNo
Voltage240 V
Depth141 mm
Height286 mm
Width286 mm

We always aim to dispatch your order for delivery on the next working day. Simply place your order before the same-day dispatch cut-off time. The countdown timer on the product page shows this cut-off time. While we work with trusted couriers, delivery times cannot be guaranteed.

Free UK Delivery on All Qualifying Orders Over £50. Orders under £50 will incur a £5.90 Delivery Fee.

This Excludes Delivery to the Scottish Highlands, Offshore Islands and Northern Ireland. These will be charged at an extra rate, which will be calculated at the checkout.

Heavier Items may also incur an extra fee.

Compare the range

Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Internal Shutters, Manual - WF230MP
WF230MP
£136.45
Duct size diameter
230 mm
Extractor type
Axial
Fan size diameter
9 in
Finish or colour
White
Humidistat
No
Ip rating
IP24
Minimum voltage
220 V
Mounting
Wall,Window
Noise level maximum
50 dB
Power consumption
41 W
Timer
No
Manrose 230mm (9") Window Extractor Fan With Internal Shutters, Automatic - WF230A
WF230A
£115.45
230 mm
Axial
9 in
White
No
IP44
220 V
Window
50 dB
41 W
No
Manrose 230mm (9") Wall/Window Extractor Fan with Pullcord & Fixed Grill - WF230P
WF230P
£102.43
230 mm
Axial
9 in
White
No
IP44
220 V
Wall,Window
50 dB
41 W
No
Manrose 230mm (9") Wall/Window Extractor Fan with Fixed Grill - WF230S
WF230S
£110.20
230 mm
Axial
9 in
White
No
IP44
220 V
Wall,Window
50 dB
41 W
No
