Product Overview

With a slim profile of only 17mm, Silhouette blends in with the wall surface to provide an unobtrusive installation. Silhouette has a FID performance of 95m3/h.

Silhouette can be ceiling/panel mounted and connected to an appropriate duct run to the outside.Single speed 100mm bathroom/toilet fan. Integral PIR operated model, (presence detector) with adjustable electronic overrun timer (up to 30 mins) neon running light and back-draught shutter.

Criteria

• Specification:
  • Noise Level: 37 (dB(A))
  • Wattage: 16 W
  • IP Rating: IPX4
  • Height: 160 mm
  • Manufacturer Code: 454058A
  • Barcode: 5015135494520
  • Dimensions: W: 160 mm
• Features:
  • Touch: Yes
  • Where to Mount: Wall
  • Hole Size: 98 mm
  • Type of Extractor: Silhouette
  • Number of Speeds: 1 Speed
  • Extractor Application: Bathroom
  • Extraction Rate: 95 (FID, m3/h)
  • Dimensions: Height: 160mm x Width: 160mm x Depth: 97mm
  • Weight: 0.60 Kg
• Manufacturer Code: 454058A

Features

• Touch: Yes
• Where to Mount: Wall
• Hole Size: 98 mm
• Type of Extractor: Silhouette
• Number of Speeds: 1 Speed
• Extractor Application: Bathroom
• Extraction Rate: 95 (FID, m3/h)
• Dimensions: Height: 160mm x Width: 160mm x Depth: 97mm
• Weight: 0.60 Kg

Short Description

Vent-Axia Silhouette 100TM Bathroom Fan with PIR - 454058A

Specification

• Noise Level: 37 (dB(A))
• Wattage: 16 W
• IP Rating: IPX4
• Height: 160 mm
• Manufacturer Code: 454058A
• Barcode: 5015135494520
• Dimensions: W: 160 mm

Specification

Applicable Area	Bathroom, Toilet
Collection Name	Silhouette
Duct Size Diameter	105 mm
Extractor Type	Axial
Fan Size Diameter	100 mm
Fan Speeds	1
Finish Or Colour	White
IP Rating	IPX4
Mounting	Ceiling, Panel, Wall, Window
power consumption	15 w
Timer	Yes
Voltage	240 v
Depth	170 mm
Height	160 mm
Width	170 mm
