Product Overview

The Solo Plus range from Vent-Axia has been specially designed for through the wall and ducted applications, suitable for internal bathrooms, toilets and other small rooms. Finished in white, the Solo Plus can be flush or surface mounted, with a 2-position 100mm circular spigot for rear entry or connecting to a vertical ducting system.

Depending on the model, the fan will switch from trickle (if selected) to boost (medium or high) via the pullcord/light switch/humidity sensor/PIR. All models can be wall, panel or ceiling mounted and can be connected to either circular, rectangular or Vent-Axia’s flat ducting. Enclosure of the electrical components is manufactured from flame retardant grade material.

Flush or surface mountable. Control by integral PIR detector. Constant trickle option. 2 Speed. Constant trickle option.

Criteria

• Specification:
  • Noise Level: 40.3 (dB(A))
  • Wattage: 23 W
  • Voltage: 220-240V/1/50Hz
  • IP Rating: IPX7
  • Height: 263 mm
  • Manufacturer Code: 427480A
  • Barcode: 5015135484286
  • Dimensions: W: 224 mm
• Features:
  • Amps: 0.2
  • Pull Cord: Yes
  • Application: Internal bathrooms, toilets and other small rooms
  • Where to Mount: Wall
  • Hole Size: 100mm
  • Type of Extractor: Extract Fan
  • Number of Speeds: 2 Speed
  • Extractor Application: Bathroom
  • Extraction Rate: 90(FID, m3/h)
  • Dimensions: Height: 263mm x Width: 224mm x Depth: 161mm
Dimensions
• Manufacturer Code: 427480

Features

• Amps: 0.2
• Pull Cord: Yes
• Application: Internal bathrooms, toilets and other small rooms
• Where to Mount: Wall
• Hole Size: 100mm
• Type of Extractor: Extract Fan
• Number of Speeds: 2 Speed
• Extractor Application: Bathroom
• Extraction Rate: 90(FID, m3/h)
• Dimensions: Height: 263mm x Width: 224mm x Depth: 161mm

Short Description

Vent-Axia Solo Plus TM Bathroom Fan with Timer and PIR - 427480

Specification

• Noise Level: 40.3 (dB(A))
• Wattage: 23 W
• Voltage: 220-240V/1/50Hz
• IP Rating: IPX7
• Height: 263 mm
• Manufacturer Code: 427480A
• Barcode: 5015135484286
• Dimensions: W: 224 mm

Specification

Applicable Area	Bathroom, Laundry Room, Toilet
Backdraft Shutter	Yes
Collection Name	Solo Plus TM
Duct Size Diameter	105 mm
Extractor Type	Centrifugal
Fan Size Diameter	100 mm
Fan Speeds	3
Finish Or Colour	White
IP Rating	IPX4
Mounting	Ceiling, Panel, Wall
Pull Cord	Yes
Voltage	240 v
Depth	330 mm
Height	150 mm
Width	330 mm
