Product Overview

With improved aesthetics, sound and installation it has been specifically designed for effective ducted ventilation of internal bathrooms, toilets and other small rooms. Finished in White.
Can be used with 100mm diameter smooth bore duct in straight runs equal to 50m, yet still meets the 15l/s required by the current Building Regulations Document F for ventilation of bathrooms. IPX4 Rated.

Criteria

• Specification:
  • Extract Performance: 80 m³/hr
  • Extract Performance: 22 l/s
  • Max Watts: 17W
  • Voltage: 230V
  • Sound@3m: 30dB(A)
  • Amps @ 240V: 0.15
  • Dimensions: H: 154mm x W: 154mm x D: 144mm
• Features:
  • 100mm high performance centrifugal extract fan for internal bathrooms, toilets and other small rooms
  • Updated design
  • Now even quieter at just 30dB(A)
  • Extract performance 24l/s
  • Single speed and overrun timer models
  • Suitable for wall, ceiling, panel and window mounting
  • SELV models suitable for installation over or within reach of a shower or bath
  • Suitable for use with flat ducting
  • IPX4 rated - IPX7 rated (SELV)
  • Transformer complies with BS EN 60742
• Manufacturer Code: 409160
• Barcode: 5015135091606

Features

• 100mm high performance centrifugal extract fan for internal bathrooms, toilets and other small rooms
• Updated design
• Now even quieter at just 30dB(A)
• Extract performance 24l/s
• Single speed and overrun timer models
• Suitable for wall, ceiling, panel and window mounting
• SELV models suitable for installation over or within reach of a shower or bath
• Suitable for use with flat ducting
• IPX4 rated - IPX7 rated (SELV)
• Transformer complies with BS EN 60742

Short Description

Vent-Axia Solo Pro T Centrifugal Fan - 409160

Specification

• Extract Performance: 80 m³/hr
• Extract Performance: 22 l/s
• Max Watts: 17W
• Voltage: 230V
• Sound@3m: 30dB(A)
• Amps @ 240V: 0.15
• Dimensions: H: 154mm x W: 154mm x D: 144mm

Downloads

Download vent-axia-409160-datasheet

Specification

Applicable Area	Bathroom, Laundry Room, Toilet
Backdraft Shutter	Yes
Bathroom Zones	Zone 1, 2
Extraction Rate Litres Second	22 l
Fan Size Diameter	4 INCH
Fan Speeds	3
Finish Or Colour	White
IP Rating	IPX4
Minimum Voltage	220 v
Mounting	Ceiling
Noise Level Maximum	30 Db
power consumption	18 w
Silent Running	Yes
Timer	Yes
Voltage	240 v
Height	154 mm
Width	154 mm
