Product Overview

The Vent-Axia Lo-Carbon Tempra P Single Room Heat Recovery Unit is available with a constant trickle speed and with a pullcord or switch to boost airflow. The units are suitable for installation into external walls up to 318mm thick and all installations can be carried out from inside a building. To facilitate ease of maintenance and installation the Tempra's simple construction is not difficult to fit in the same location as an existing 100mm diameter fan and offers easy access to the heat exchanger for regular maintenance. Under the Building Regulations Document F, continuous running products such as the Lo Carbon Tempra are only required to move an amount of air as laid down in table 5.1a of Document F.

Criteria

• Specification:
  • Extract Performance: 80 m³/hr
  • Extract Performance: 22 l/s
  • Max Watts: 19W
  • Voltage: 230V
  • Sound@3m: 30dB(A)
  • Amps @ 240V: 0.26
  • Dimensions: H: 154mm x W: 154mm x D: 144mm
• Features:
  • 100mm high performance centrifugal extract fan for internal bathrooms, toilets and other small rooms
  • Updated design
  • Now even quieter at just 30dB(A)
  • Extract performance 24l/s
  • Single speed and overrun timer models
  • Suitable for wall, ceiling, panel and window mounting
  • SELV models suitable for installation over or within reach of a shower or bath
  • Suitable for use with flat ducting
  • IPX4 rated - IPX7 rated (SELV)
  • Transformer complies with BS EN 60742
• Manufacturer Code: 443312
• Barcode: 5015135433123

Features

• 100mm high performance centrifugal extract fan for internal bathrooms, toilets and other small rooms
• Updated design
• Now even quieter at just 30dB(A)
• Extract performance 24l/s
• Single speed and overrun timer models
• Suitable for wall, ceiling, panel and window mounting
• SELV models suitable for installation over or within reach of a shower or bath
• Suitable for use with flat ducting
• IPX4 rated - IPX7 rated (SELV)
• Transformer complies with BS EN 60742

Specification

• Extract Performance: 80 m³/hr
• Extract Performance: 22 l/s
• Max Watts: 19W
• Voltage: 230V
• Sound@3m: 30dB(A)
• Amps @ 240V: 0.26
• Dimensions: H: 154mm x W: 154mm x D: 144mm

Specification

Applicable Area	Bathroom, Toilet
Collection Name	Lo-Carbon Tempra
Duct Size Diameter	105 mm
Extractor Type	Heat Recovery
Fan Size Diameter	100 mm
Fan Size Diameter Inches	4 INCH
Fan Speeds	3
Finish Or Colour	White
IP Rating	IPX4
Mounting	Wall
Voltage	240 v
Depth	585 mm
Height	250 mm
Width	585 mm
